ROTO 50.21 S-PLUS

Find your perfect merlo

Merlo ROTO 50.21 S-PLUS Overview

The telescopic handlers of the Roto range allow 360 degree operation thanks to the rotating turret, which offers a greater range of action compared to a fixed telescopic handler. This S PLUS models represents the top of the range, a true concentration of technology and performance that’s destined to remain a leader in world markets. This is also thanks to the prestigious awards already won by the previous Roto ranges.



MODEL FEATURES



  • Continuous 360° rotation;
  • ROTO50.21 S-Plus can lift 5000kg, for a maximum lift of 21 m.
  • The ROTO S-PLUS models with 125kW/170HP engine, are combined with the Eco Power Drive (EPD) electronic management that automatically controls and adjusts the engine revolutions based on operating conditions. This technology achieves a reduction in fuel consumption of up to 18%.
  • Multi-position stabilisers with automatic self-levelling and self-stabilisation;
  • Tilting cab: the exclusive Merlo cab ensures greater levels of comfort, ergonomics and safety. From the driver’s seat the operator can activate the cab’s tilting via the dedicated button. The longitudinal inclination reaches 20°, allowing you to monitor the movements of the load when working at a height;
  • Intelligent hydropneumatic suspensions on axles, giving great frame levelling control (12% lateral and 4% front inclination) and the possibility to the machine when is on wheels of varying the height according to the soil;
  • Exclusive MCDC (Merlo Dynamic Load Control): the system allows you to collect different parameters submitted by the machine, analyse them in real time and create a load diagram that allows the operator, through the new LCD display, to understand the perimeter within he/she can operate in maximum safety;
  • Double hydraulic Load Sensing and Flow Sharing pumps which provide greater system efficiency, simultaneous movements, more precision movements, lower consumption and less overheating of components and oil.
  • S-PLUS models come as standard with Grammer Warmed Seat, Roof Wiper, Sunshade, LED light on cab, Lights on boom, Towing Hook and Prearrangement for platform.







Engine: FPT 4.5 125Kw/170 Hp Stage IV

Transmission: Hydrostatic

Hydraulic system: 2 x Load Sensing + Load Sharing, 138+100 l/m – 250/230 Bar

Electronic Joystick

Cab: premium

Multiposition stabilisers

Merlo ROTO 50.21 S Overview

The telescopic handlers of the Roto range allow 360 degree operation thanks to the rotating turret, which offers a greater range of action compared to a fixed telescopic handler. The new Roto family marks a new era by introducing new standards in the field of telescopic handlers for the construction sector and expanding the product range with new contents, adapting more and more to the needs of different users.

MODEL FEATURES


  • ROTO 50.21 has a maximum capacity of 5000kg for a lift height of 21 meters.
  • The ROTO50.21 S-classic allows a continuous 360° rotation, equipped with intelligent Hydropneumatic Suspensions on axles as standard, giving the possibility to the machine when is on wheels of varying the height according to the soil.
  • This S-Classic models with 170 HP engine, are combined with the Eco Power Drive (EPD) electronic management that automatically controls and adjusts the engine revolutions based on operating conditions. This technology achieves a reduction in fuel consumption of up to 18%.
  • Exclusive MCDC (Merlo Dynamic Load Control): the system allows you to collect different parameters submitted by the machine, analyse them in real time and create a load diagram that allows the operator, through the new LCD display, to understand the perimeter within he/she can operate in maximum safety.
  • The Tilt Correction System, integrated into the chassis, is available as standard on this model: it allows the operator to offset the ground slopes to work in total safety. On sloping terrain the operator can correct the lateral inclination by 10% and frontal inclination by 8%.
  • ROTO machines are equipped as standard with Self-stabilisation and Self-levelling on stabilisers: this allows greater ease of use, less wasted time for the stabilisation phases and the possibility of correcting transversal and longitudinal slopes.
  • The hydrostatic transmission guarantees maximum precision in movement and load‘s positioning.


Engine: Deutz 3.6 125Kw/170Hp Stage IV

Transmission: Hydrostatic

Hydraulic system: Load Sensing + Load Sharing 138 l/m 250 Bar

Electronic Joystick

Cab: premium

Multiposition stabilisers

Lift capacity 5000kg

Lift height 21 meters

Tilting cab

Automatic self-levelling on stabilisers & self-stabilisation

Dynamic Load Control + Double hydraulic pumps

Download Brochure Icon

Download Brochure

Spare Parts Icon

Spare Parts

Dealer Icon

Find a dealer

Attachments

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments. Please download our latest attachment brochure to see the full range.
